The dichotomy between keeping an enclosed space available for big musical events and trying to protect your turf is clearly evident whenever concerts of the massive proportions that large scale music and rock concerts take place inside a stadium. The sheer volume of staff, stages and lighting and staging equipment used by thousands can destroy any perfectly manicured sports surface within mere hours. Yinghui provides a system of robust heavy duty concert flooring which acts as the perfect and highly professional solution that not only creates a high level of surface protection on the field itself down at playing level but can help to restore the playing surface for use once more for a match in between hosting amazing live events.
Advanced Load-Bearing Technology for Safe Events
One of the basic problems to solve when trying to protect turf for concerts in a stadium environment is weight distribution. Heavy equipment and lighting towers put a tremendous amount of pressure on the ground, and can compact soil and harm root systems, when moved with a full-infill and equipped with lights. This is a challenge that has been taken head-on by Yinghui's T-04 flooring.
The T-04 model is made from 100% virgin polypropylene, and it provides outstanding compressive strength. The non-cable version (T-04R) achieves an impressive 588,275 kg/m² (120,488 lbf/ft²), while the cable-compatible version (T-04C) provides 326,025 kg/m² (66,775 lbf/ft²) . This technology allows them to put stage equipment, forklifts and trucks right on the surface of the turf without severely damaging the sod below. SGS testing revealed an ultimate load capacity of 10,307 N over a loading area of 25.4 mm x 25.4 mm, proving that the tiles are capable of meeting the strenuous requirements of stadium concerts.
The interlocking connection system forms a continuous monolithic surface with no space between pieces, avoiding trip hazards. The locking tabs are specially designed that provide a tight fit and resist pulling or vehicle shoving . Fire safety is also covered – UL94 HB or UL94 V-2 as required for projects. Flooring can be used in various climates as the material is temperature tested from -40°C to + 70°C for 24 hours.
Breathable Design for Turf Health and Ventilation
Unlike solid temporary flooring (which can smother grass), yields are focused on promoting the health of the turf. The water and air circulate through the strategically placed holes on the top of the T-04, ensuring that water and air continue to reach the natural grass below and supporting it for additional extended periods of covering. It creates a "breathable" seal to keep grass alive and healthy underneath the cover.
Another turf protection measure is drainage channels which help to reduce the amount of liquids and debris spread across the turf and cause poolings that can harm the turf. The modular system provides a means for air circulation and keeps turfs healthy when using long term event coverage. The translucent property of the material also allows the sun's energy to pass through enabling continued photosynthesis.
Another important characteristic is UV resistance, where the tiles were able to last for 1,500 hours of aging without discoloring, powdering or cracking. The durability prevents a loss of function from the changing tropical environments or venues as well as from different weather conditions, guaranteeing long lasting protection and profits. The five-year warranty also reflects that the company believes in the long life of the products.
Premium Surface Stability for Stage Setups
For people who organise and perform at events it affects their safety and their production process. The floor level and stable surface of Yinghui's flooring material could withstand the requirement of professional stage props. The anti-slip surface provides safe footing for the performer and crew even under some tough conditions, and helps to make the event setting safe.
The system can allow the power cable to be buried beneath surface, thus no ugly and dangerous exposed power cables will be seen in the performance area. The integration makes stage set up easier and makes both safety and aesthetics easier along the way. The flexible connection system makes for easy installation and removal of the flooring, without causing breakage, and is engineered to ensure the floor will not be damaged during multiple uses.
The uses of being modular also allow for quick setup and take-down of facilities, enabling venues to run a more efficient event in order to maximize revenue opportunities. If paired with lighter pedestrian skins it will form a tailored, all-in-one flooring solution for any event's requirements. Its flexibility ensures that Yinghui's flooring is the go-to option for grand concerts and entertainment events in 72 countries.
The concert flooring offered from Yinghui is a heavy-duty type of product that can support high loads, so it is an excellent choice for use in event productions. The concert flooring supplied by Yinghui is a heavy duty model which easily takes high loads and protect the turf. Advanced engineering and careful design for optimum turf health makes it possible for venues to throw amazing events and maintain the playing surface as their most important resource.
